Bottom Seal Bag Making Machine
The Bottom Seal Bag Making Machine is an advanced and efficient solution for manufacturing high-quality plastic bags with bottom sealing configurations. Designed for precision and speed, this machine is ideal for industries producing packaging materials for a wide range of applications, such as retail, food packaging, garment bags, and industrial uses.
Specifications
| DECRIPTION | SPECIFICATION |
|---|---|
| Maximum Width | 150mm / 6" inch |
| Maximum Width | 800mm / 32" inch |
| Minimum Length | 70mm / 4" inch |
| Maximum Length | 2500mm / 100" inch |
| Maximum Web Width | 810mm / 32" inch |
| Tube Thickness | 60mic to 200mic |
| Maximum Speed | 160 bags/min * |
| Total Power | 7kW |
| Machine Dimensions | 3900mm(L) x 1320mm(W) x 1550mm(H) |
Compatible Materirals : Plain or Printed, Bio De-Compostable (PLA) LD-LLDPE, HM-HDPE, PP Tube Form
* DEPENDING ON THE SIZE & FILM THICKNESS
- Main draw roller servo driven, controlled by PLC
- Film cut sensor for loading
- High speed color makr sensor
- Auto ERROR message with machine off
- Print mark protection
- Addional Roll Loading Unit
- Bottom Gusset Sealer
- Cross Sealer
- Online Punch
- Single structure LASER CUT machine.
- Time for installing the machine after unloading is 3 to 4 hrs.
- Wiring type PLUG & PLAY.
